| Display | 4 Digit 0.56″ 7 Segment Red LEDs for Temperature 2 Digit 0.56″ 7 Segment Green LEDs for Channel Number |
| Number of Channels | Maximum 16 |
| Sensor | J,K,R T/C or 3 wire PT-100 (common for all channels) |
| Range | : J T/C : -50°C to 750°C K T/C : -50°C to 1250°C R T/C : 0 to 1700°C PT100: -100.0 to +600.0°C |
| Resolution | 1°C for thermocouples and 0.1°C for PT100 |
| Accuracy | ±0.1% of F.S. ±1 Digit |
| Serial Output | RS-232 output |
| Logging Rate | Settable in Hours:Mins (00:01 to 23:59 ) RTC controlled with batterybackup to save 3000 readings |
| Real Time Clock | Adjustable in Hours:Mins and Month/Date |
| Auto/Manual mode | Toggle between Auto/Manual modes with front panel indication of mode |
| Display Rate | 1 to 99 seconds per channel in Auto Mode |
| Memory | Non-volatile EEPROM for saving settings |
| Configuration Locks | 1. At rear terminals to lock number of channels 2. At rear terminals to lock Clock settings |
| Supply | 220V AC ± 15% at 50/60Hz |
| Ambient Temp. | Maximum 55°C |
| Size (Front) | 96 x 192 mm |
| Depth | 170 mm |
