Display | 4×20 line 0.3” character height alphanumeric LCD module display |
Sensor | J/K/R Thermocouples and 3 wire PT100 sensor user selectable |
Range | J-T/C : 0 to 750°C K-T/C : 0 to 1250°C R-T/C : 0 to 1700°C PT100: -100.0 to +600.0°C |
Resolution | 1°C for thermocouples and 0.1°C for PT100 |
Channels | Maximum 16 |
Scanning Rate | User settable from 1-99seconds |
Digital Offset | User settable individually for each channel |
Logging Rate | 1 second to 99Mins 59seconds |
Data Logging | Directly create a .csv file on the Pen Drive (compatible with Excel) giving a tabular format values of Date, Time and selected channels |
Real Time Clock | Adjustable Calendar (Month/Date) and Time (Hrs:Mins) |
Accuracy | ±1°C ± 1 Least Significant Digit for Thermocouples ±0.1°C ± 1 Least Significant Digit for PT100 |
Power Supply | 230V AC ± 15% at 50/60Hz |
Mounting Type | Panel Type |
Front Facia | 96mm x 192mm |
