We have reached the pinnacle of success and earned a reputed name by providing the high-quality range of CNC Routers.

Technical Parameters:

• X .Y Axis working area : 1300X2500mm

• Z-Axis working area: 200mm

• Repeatability : 0.025(+/-mm)

• Max Cutting Speed : 20000mm/min

• Rapid Traverse : 30000mm/min

• Spindle power rate: 3.5K/4.5KW/6 KW (air-cooled)

• 2KW/4.5KW/6 KW (water-cooled)

• Spindle rotating speed: 0-24000rpm (water-cooled)

• 0-18000rpm (air-cooled)

• Command : G code*.u00*.mmg*plt

• Work Mode: Step Motor

• Transmission: X Y helical rack gear, Z ball screw

• Guideway: Linear guideway(win)

• Control system : Ncstudio / DSP Controller

• Weight: 1120Kgs

• Power: AC380V/60Hz

Suitable Industry:

• Suitable for high-volume processing of non-ferrous metal sheets, such as PVC board, acrylic, insulation materials, wood and composite panels.

• Suitable for sheet processing, cutting, slotting, engraving, etc. Performance Characteristics: Imported D-Link.

*Warranty- One year
