Parishram Technocrats

Laminate Sanding Machine Single Head Heavy Duty

₹ 2596000.00  Incl. GST/Nos ₹ 2200000 Excl. GST

Description

Laminates are either calibrated to Thickness with our sanding machines or roughened for later production steps.
Laminates are either calibrated to Thickness with our sanding machines or roughened for later production steps. The tolerances during calibration are in the range of +/-0.005mm. The requirements for high-pressure Laminates HPL and continuous Pressure Laminate CPL are the same. With CPL, however, there is the additional requirement that the sanding machine must run absolutely synchronously with the upstream laminate press, as these are non - flexible endless workpieces.
 Main Roll - Steel Roll with growing Dia. 320mm
Pressure Roll - Rubber Roll - Dia.240mmPressure Roll UP DOWN by ball screw with gearbox system Servo drive with PLC setting
Sanding belt size - 1320/ 2650 mm Display on a panel with HMI Auto setting system servo drive with PLC with cylinder setting.

Laminate Sanding Machine Single Head Heavy Duty

Product ID (MPN): ITB-92AE0B14
Availability:In Stock
₹ 2596000.00  Incl. GST ₹ /Nos
Brand Name Parishram Technocrats
Model ITB-92AE0B14
Condition New
Unit Type Nos
Minimum Order Quantity 1
Minimum Ordered Packs 1
Country of Origin India
Taxes Inclusive of Tax
Ships from Ahmedabad
Shipping Product eligible for free shipping
Returnable 7 Days Return
Warranty Type Manufacturer / Seller
Warranty Not Applicable
SELLER INFORMATION
Parishram Technocrats
Business Address
24, Akshar Industrial park, Behind Amba Esatate, Vinzol Patiya, Mehmdavad Road, Vatva , Ahmedabad Gujarat -382445
  • Description
    Laminates are either calibrated to Thickness with our sanding machines or roughened for later production steps.
    Laminates are either calibrated to Thickness with our sanding machines or roughened for later production steps. The tolerances during calibration are in the range of +/-0.005mm. The requirements for high-pressure Laminates HPL and continuous Pressure Laminate CPL are the same. With CPL, however, there is the additional requirement that the sanding machine must run absolutely synchronously with the upstream laminate press, as these are non - flexible endless workpieces.
     Main Roll - Steel Roll with growing Dia. 320mm
    Pressure Roll - Rubber Roll - Dia.240mmPressure Roll UP DOWN by ball screw with gearbox system Servo drive with PLC setting
    Sanding belt size - 1320/ 2650 mm Display on a panel with HMI Auto setting system servo drive with PLC with cylinder setting.
