Our range of products include High Speed Double Sided Rotary Tablet Press Machine, Double Sided Rotary Tablet Machine, 37 Stn High Speed Double Sided Rotary Tablet Press Machine, Single Sided Rotary Tablet Press Machine, Non GMP Single Sided Rotary Tablet Press Machine and Mini Rotary Tablet Press Machine.
Features:
- High Speed Double Sided Rotary Tablet Press Suitable for Large Batch Production
- This Machine Is Available With Pre-compression Roller Ability to Compress Variety of Products Easily
- Outside Controls for Tablet Weight and Hardness
- Force Feeding System Are Zero Clearance
- Powder Level Sensing (Optional)
- Upper Side Guards Is Acrylic and Lower Guards Ss 304
- Electromagnetic Clutch
- Hydraulic Power Pack for Pressure Loading and Overload
- Release Pre-compression Facility
- Ac Variable Drive Is for Main Motor and Force Feeder
- Front Side Easy Outside Controls for Tablet Parameters Setting
- Two Layer Attachment (Optional)
- Plc With Touch Screen Control System (Optional)
- Separate Control Panel (Optional)
- Turret on Electroless Nickel Plating (Optional)
Product details:
|
Capacity
|
324000 Tablet/hr
|
|
Brand
|
Digicon
|
|
Model Name/Number
|
DPM-IV-45
|
|
Frequency
|
50-60 Hz
|
|
Material
|
SS
|
|
Voltage
|
220-240 V
|
|
Weight
|
3600 Kg
|
|
Country of Origin
|
Made in India
|
|
Dimension
|
1450 mm x 1600 mm x 1950 mm
|
|
Feeder Motor
|
0.25 Hp/1440 RPM/3 Ph
|
|
Main Electric Motor
|
10 Hp/1440 RPM/3 Ph
|
|
Upper Punch Penetration
|
1.5 to 8 mm
|
|
Max Depth of Fill
|
20 mm
|
|
Max Tablet Diameter
|
25 mm
|
|
Pre Pressure Max
|
1 Ton
|
|
Max Main Pressure
|
10 Ton
|
|
Type of Tooling
|
D
|
|
Number of Station
|
45 Station
|
