TECHNICAL DATA OF FIX CONCRETE BATCHING PLANT - 25 Cu. M/HR (PAN)

MODEL CP-25 (Pan) type

Type                                      Fix

OUT CAPACITY                  25 M3 / HR.

HOPPERS                     2/4 bins type X 2.5 M3 (Each bins)

BATCH CAPACITY               0.45 CU.M / 450 LTRS.

WATER PUMP               2.0 H.P

ADDITIVE PUMP               SELF PRIMING

CEMENT SILO                     1.5 TONS

DISCHARGE HEIGHT        12 feets

CONTROL CABIN              Width 5 feet X Length 7 feet X Height 6 feet.

POWER REQUIRED           52 HP

POWER SUPPLY                415 V, 50 Hz, 3 PHASE,  A.C. MOTOR

WEIGHING CONVEYOR      5.0    HP

CHARGING CONVEYOR    5.0    HP

PAN MIXER                      25.0 HP

WATER PUMP                   2.0    HP

SCREW CONVEYOR          7.5    HP

ADDITIVE PUMP               0.5    HP

HOPPER VIBRATOR         0.5    HP

CEMENT VIBRATOR         0.25 HP

CEMENT WEIGHER          0.25 HP

COMPRESSOR                   3.0    HP

HYDRAULIC POWER PACK 3.0    HP
